Category Archives: Head No. Lookup

Nov

Support List of WD HDD Head Replacement Tools

Head No. Lookup, News & Tips HeadMaster

WD HDD Head Replacement Tools: WD Slim HDD Head Comb Suite.AdvancedWestern Digital HDD Head Comb Suite WD slim hdd replacement tools for: WD10SPCX, WD10S12X , WD5000MPCK, WD5000M22K, WD5000MTCK, WD5000M13K, WD5000M21K, WD7500L12X WD40NMZW-11GX6S1 WD30NMZW-11GX6S1 WD30NPZZ-00PDPT0 WD30NMRW-11YL9S4 WD30NMVW-11C3NS2 WD30NMVW-11C3NS4 WD60PURX-64LZMY0 WD60EZRZ-xxRWYBx WD50EZRZ-xxRWYBx WD10JMVW-11AJGS4 WD20NMVW-11EDZS2 WD10JMVW-11AJGS3 WD10EALX-009BA0 (3 platters) WD60EFRX-68L0BN1 WD50EFRX-68MYMN1 WD60EZRX-00MVLB1 .

Jan

ST1000LM035-1RK172 EB01 HDD Repair ID Info

Head No. Lookup, News & Tips HeadMaster

Model : ST1000LM035-1RK172Serial : ZDEHKACWFirmware : EB01Capacity : 1953525168 (931.51GB)Sector size : 4096Heads number : 2 FW info : ObtainedFW version : R1AEA0684.SDM4.AA4901.EB01FW package P/N : 100849196FW ID : 00305567FW creation date : 2019/01/22FW creation time : 20:23:32CFW version : R1AEA0684.SDM4.AA4901.01618036.0SFW1 version : 0305567.EB01

Dec

ST2000LM007-1R8174 HDD Repair ID Info

Head No. Lookup, News & Tips HeadMaster

Model : ST2000LM007-1R8174Serial : WDZCVF7KFirmware : SBK2Capacity : 3938101240 (1877.83GB)Heads number : 4 CheopsLiteM.1.0.SATA.Rosewood.Mule.Servo376.Rap30.AP1.4K + SMRProduct FamilyId: A5, MemberId: 01HDA SN: WDZCVF7K, RPM: 5456, Wedges: 178, Heads: 4, OrigHeads: 4, Lbas: 00001D5754FF, PreampType: 82 12Bits/Symbol: C, Symbols/UserSector: 0, Symbols/SystemSector: 0PCBA SN: 0000K8322DX7, Controller: CHEOPSLITEM_1_0_SATA(1310), Channel: Unknown, PowerAsic: KONA Rev .

May

ST3000LM024 ST4000LM024 ST5000LM000 and Head Replacement Tool

News & Tips, Seagate HDD Heads & Platters HeadMaster

ST3000LM024 ST4000LM024 ST5000LM000 data recovery are common Seagate data recovery cases in many data recovery labs. For physically damaged hard drives such as damaged heads or scratched surfaces or weak heads, it is necessary to edit the head map in rom and set up head map in disk image .

Aug

WD HDDs with 1.5-1.67TB Each Platter

News & Tips, WD HDD Heads & Platters HeadMaster

WD6003FRYZ-xxF0DBx 6TB 4 platters 8 headsWD8004FRYZ-xxVAEBx 8TB 5 platters 10 headsWD102KRYZ-xxA5ABx 10TB 6 platters 12 headsWD6003FZBX-xxK5WBx 6TB 4 platters 8 headsWD6003FFBX-xxMU3Nx 6TB 4 platters 8 headsWD80EFAX-xxKNBNx 8TB 5 platters 10 headsWD8003FFBX-xxB9ANx 8TB 5 platters 10 headsWD80EMAZ-xxM9AAx 8TB 5 platters 10 headsWD101EFAX-xxLDBNx 10TB 6 platters 12 heads

Aug

WD HDDs with 2TB Each Platter

News & Tips, WD HDD Heads & Platters HeadMaster

As the CAP and TPI are increasing quickly, pc users get hard drives of bigger and bigger capacity, each platter can hold much more than before. WD20EFAX-xxFB5Nx 2TB, 1 platter 2 heads WD30EFAX-xxJH4Nx 3TB, 2 platters 3 heads WD40EFAX-xxJH4Nx 4TB , 2 platters 4 heads WD40EMAZ-xxTKPBx 4TB, 2 platters .

Jul
